Projects using HDPE Pipeline Industrial and Irrigation Projects – large diameter pipe
Agru America is a supplier of high quality innovative HDPE products up to 3,500 mm diameter pipes.
1. Melbourne Water – Werribee STP
DN1800mm
2. FMG – Pilbara Iron Bridge
DN1200mm / DN1000mm / DN800mm
3. Gladstone to Fitzroy Pipeline
DN1200mm
4. TasWater – Midland’s Pipeline
DN1200m / DN1000m
5. Central Plains Water Board
DN1400mm, 130km
6. Proposed Toowoomba to Warwick Pipeline DN800mm / DN500mm / DN250mm PN20
7. Water NSW – Peel Drought Relief Pipeline
DN710mm HDPE, 18.2km
8. Santos – GLNG Field Development Project
DN900mm HDPE, 1300km
11. Arrow Energy – Gathering Network Program (MSA)
DN110-DN800mm HDPE, 470km
9. Murrumbidgee Irrigation NSW – Pipeline Channel Replacement
DN450-DN1000mm HDPE
10. Terra Ag Pipeline – Channel Replacement
DN900mm HDPE
12. Sydney Water – Badgerys Creek
DN1000mm
13. TasWater – Huon Outfall
DN1600mm
14. Mosaic Fertilisers, Florida USA
DN1400, DN710 up to 150 metres in length.
Annual production: 24,000 tonnes of HDPE pressure pipe.
14. An example of reticulation construction HDPE pipe technology used in New Zealand.
The pipe distribution network consists of several pump stations and four main pipelines extending from the headrace canal down the Canterbury Plains to supply farms requiring irrigation.
The four main pipelines were constructed between May 2014 and August 2015.
With 130km of pipe to lay, contractors worked simultaneously on all main pipelines, and up to six days a week.
The pipes are buried at a depth of no less than 900mm to prevent pipe floatation and to avoid potential impact from agricultural activities.
